SKU: DH.WHM1203-Parent
Aluminium case Flask Heating Mantles. Stirring Type
Available on Backorder
Categories: Heating MantlesSKU: DH.WHM1203-Parent
Product Enquiry
- Ideal for all types of round flasks
- With Powder-coated Steel-case
- With Certificate & Traceability: Controlled by Serial Number, Certificate, Delivery-information, and Traceable Data Base System
- Built-in Temp-Controller. Nickel-Chrome Heating Element “Coil-type” – Max 450°C
- 10L model has square-type outside shape
- Includes 1 × PTFE Oval-type Magnetic Stirrer Bar, L25mm
| Code | Flasks, ml Dia. Φ mm |
Mantle | ||
| Watts (W) | Inside Depth | Outside Φ× h(mm) |
||
| DH.WHM12031 | 100ml, Φ63 ~ 66 | 80 W | 40 mm | Φ150×h140 |
| DH.WHM12032 | 250ml, Φ83 ~ 86 | 140 W | 50 mm | Φ150×h140 |
| DH.WHM12033 | 500ml, Φ102 ~ 105 | 240 W | 65 mm | Φ200×h165 |
| DH.WHM12034 | 1,000ml, Φ130 ~ 133 | 350 W | 75 mm | Φ200×h165 |
| DH.WHM12035 | 2,000ml, Φ165 ~ 169 | 450 W | 100 mm | Φ270×h200 |
| DH.WHM12037 | 5,000ml, Φ221 ~ 224 | 800 W | 131 mm | Φ325×h226 |
| DH.WHM8060 | 10Lit, Φ278 ~ 282 | 1,500 W | 210 mm | 440×510×h310 |
| Volume | 100ml, 250ml, 500ml, 1000ml, 2000ml, 5000ml, 10Ltr |
|---|
