SKU: ED-50
50ml Electronic Dispenser
Available on Backorder
Categories: Bottle Top DispensersSKU: ED-50
Product Enquiry
The ED-50 is an electronic bottle top dispenser with integrated burette functionality, designed for accurate dispensing and titration up to 50 ml. It replaces traditional manual dispensers and burettes while improving precision, repeatability, and ease of use.
Key Features:
- Dual function: Electronic dispenser and electronic burette in one unit
- High accuracy: ISO 8655 compliant and GLP ready
- Dispensing modes: Serial and stepper dispensing
- Touchscreen control: 4 inch TFT display with stylus
- Programmable memory: Stores up to 10 dispensing programs
- Recirculation mode: Returns reagent to bottle during purging to reduce waste
- FlexiNozzle®: Adjustable horizontally and vertically for easy access
- Motor driven piston: Consistent volume delivery and repeatability
Technical Specs:
- Volume range: 0.005 to 50ml
- Increment: 0.01ml
- Accuracy: ±0.05 percent or ±0.025 ml
- CV: ±0.05 percent or ±0.025 ml
- Materials: ABS housing, borosilicate glass, FEP tubing, PTFE piston
- Operating temperature: +10 °C to +40 °C
- Power supply: 18V, 3A
- Calibration: Electronic user calibration
- Autoclavable: No
- Languages: English, Spanish, German
Supplied with five bottle adaptors (28 mm, 32 mm, 38 mm, 40 mm, 45 mm). Optional mini printer available for GLP documentation
| Volume | 0.01-50ml |
|---|
