Explosion-Proof Laboratory Refrigerator – ATEX Certified | +3°C to +16°C Precision Cooling

Product Overview

This 360° Explosion-Proof Laboratory Refrigerator is engineered for safe and stable storage of temperature-sensitive and flammable materials in high-risk laboratory and industrial environments. Featuring ATEX II C-T6 EU Explosion-Proof Certification, this refrigerator meets stringent European safety standards and ensures superior internal protection.

Key Features

  • ATEX II C-T6 Certified Explosion-Proof Interior
    Built with a fully sealed, explosion-proof structure to meet European Union safety regulations, ensuring safe operation even in volatile environments.
  • Precise Temperature Control from +3°C to +16°C
    Offers an adjustable temperature range with ±3°C variation, delivering outstanding temperature uniformity for optimal specimen and reagent preservation.
  • Smart Alarm System with One-Key Historical Data Access
    Features a comprehensive alarm system that detects temperature fluctuations, power failures, and door status. The one-key search function enables quick retrieval and saving of historical data, streamlining compliance and inspection processes.
  • Laboratory-Grade Performance & Data Integrity
    Perfect for use in laboratories, research institutions, and medical facilities that demand secure, traceable temperature management for critical samples and chemicals.

Category HLR-310SF HLR-118SF
Type Upright Under-Counter
Climate Class N, ST N, ST
Cooling Type Forced Air Cooling Forced Air Cooling
Defrost Mode Auto Auto
Refrigerant R600a R134a
Noise [dB(A)] 40 38
Temp Range (°C) 3~16°C Adjustable 3~16°C Adjustable
Ambient Temp (°C) 16~38°C 16~38°C
Controller Microprocessor Microprocessor
Display LED LED

Electrical & Capacity

Category HLR-310SF HLR-118SF
Power Supply (V/Hz) 220 / 50 220 / 50
Power (W) 210 140
Electrical Current (A) 1.26 1.03
Capacity (L/Cu.Ft) 310 / 10.9 118 / 4.2

Dimensions & Weight

Category HLR-310SF HLR-118SF
Net/Gross Weight (kg) 72 / 83 44 / 49
Interior Dimensions (mm) 560×500×1290 515×415×630
Interior Dimensions (in) 22.0×19.7×50.8 20.3×16.3×24.8
Exterior Dimensions (mm) 605×598×1840 597×635×810
Exterior Dimensions (in) 23.8×23.6×73.6 23.5×25×31.9
Packing Dimensions (mm) 680×690×1940 700×710×930
Packing Dimensions (in) 26×26.4×79.5 26.8×27.2×35.8
Container Load (20’/40’/40’H) 24 / 51 / 51 48 / 96 / 96

Alarm & Features

Category HLR-310SF HLR-118SF
High/Low Temp Alarm ✔ ✔
Sensor Error Alarm ✔ ✔
Door Ajar Alarm ✔ ✔
Password Protection ✔ ✔
Boot Delay Protection ✔ ✔
Display Lock ✔ ✔

Accessories

Category HLR-310SF HLR-118SF
Shelves/Baskets 4 / 0 2 / 1
Water Tray 1 1
Padlock Adapter Kit 1 –
Built-in Door Lock 1 1

Build & Materials

Category HLR-310SF HLR-118SF
Exterior Material Sprayed Cold Plate Sprayed Cold Plate
Interior Material/Color PS Plate / White PS Plate / White
Insulation Cyclopentane/Isopentane Cyclopentane/Isopentane
Door Type/Qty Foaming Door / 1 Foaming Door / 1
Door Sealing Sealing Strip Sealing Strip
Shelves Material/Qty Tempered Glass / 4 Tempered Glass / 2
Adjustable Shelves ✔ ✔

Compressor & Cooling

Category HLR-310SF HLR-118SF
Compressor Type Fully Closed Fully Closed
Brand Donper Secop
Power (W) 138 172
Quantity 1 1
Condenser Type Wire & Tube Forced Back Condenser
Condenser Material Steel Tube Steel Tube
Fan EBM No
Temp Uniformity (°C) ±3 ±3
Temp Accuracy (°C) 1 1

Energy & Compliance

Category HLR-310SF HLR-118SF
Power Consumption (kWh/24h) 1.05 0.56
Certifications CE ATEX CE ATEX
Temperature Sensor 1 Resistance Thermometer 1 Resistance Thermometer
Weight N/A
