Refrigeration Power Supply

Rapid Freezing System for Clinical Pathology & Histology Laboratories

Advanced Cryo-clamp & Cryo-console | Compatible with YIDI Microtomes

The Advanced Cryo Freezing System is specifically designed for hospitals, epidemic prevention units, agricultural and forestry sectors, and a wide range of scientific research institutions. It incorporates cutting-edge thermostatic semiconductor technology for efficient and stable freezing in both the Cryo-clamp and Cryo-console, ensuring reliable specimen preparation.

This high-performance cryo system is built using advanced nanomaterial power supply technology, making it lightweight, energy-efficient, and virtually silent during operation. Its fast cooling, auto-defrost, and temperature recovery features are optimized to prevent tissue damage and streamline the clinical frozen sectioning process.

---

❄️ Key Features

• Wide Application: Trusted in clinical pathology, histology, agriculture, and scientific research labs.
• Nanomaterial Power Supply: Lightweight and noiseless with excellent power efficiency.
• Rapid Cooling Speed: Reaches ultra-low temperatures swiftly—ideal for delicate tissue freezing.
• Cryo-clamp & Cryo-console: Operate at precision-controlled temperatures for uniform tissue slicing.
• LCD Dual Temperature Display: Real-time monitoring of Cryo-clamp and Cryo-console.
• Automatic Defrost & Recovery: Returns to the pre-set working temperature within 2–7 minutes.
• Optimized Angle Design: 45° tilt between Cryo-console and Cryo-clamp enhances tissue adhesion for slicing.
• Magnetic Cryo-console: Easy installation and disassembly via magnetic adsorption.
• Improves Tissue Sectioning Quality: Suitable for both fast frozen sections and paraffin sectioning.
• Universal Compatibility: Fully compatible with all YIDI paraffin rotary microtomes.

---

🔧 Technical Specifications

• Slice Thickness Range:
• YD-355ATIII: 0.5–600/999 μm
• YD-335AIII: 0.25–600/999 μm
• YD-335III: 0.5–500 μm
• YD-315III: 0.5–60 μm
• YD-2508III / YD-1508RIII: 1–30 μm
• YD-202AIII / YD-202III: 1–25 μm
• Max Cold Storage Area: 40 × 40 mm
• LCD Display: Simultaneous readout of Cryo-clamp and Cryo-console temperatures
• Max Freezing Stage Temperature Difference: ≥ 60°C
• Max Cooling Knife Temperature Difference: ≥ 50°C
• Temperature Recovery After Defrost: Within 2–7 minutes
• Max Freezing Temperature: -20°C
