SKU: EVO HM1-10M set
Homo Mixer Set
| Sale Units | Pieces per ea |
|---|---|
| ea | 1 |
Only 1 left in stock
Categories: HomogenizersSKU: EVO HM1-10M set
Product Enquiry
The EVO HM1-10M Set from DAIHAN Scientific is a powerful, precision-engineered homogenizer ideal for laboratories and industrial applications. It’s designed for emulsifying, mixing, and dispersing even the most challenging samples with ease and accuracy.
Key Features
- Brushless DC motor for quiet operation, smooth performance, and a long service life
- Automatic reverse operation for more effective emulsification, especially when working with powders in liquids
- Forward mixing can cause powders to scatter—reverse mode helps ensure proper absorption and mixing
- Precise digital speed control protects equipment and ensures consistent results
- Can be upgraded to a disperser with the optional DSTL Disper tool (same motor, different head)
- Telescopic stand included for stable, adjustable setup
- Large 3.5-inch high-resolution color touchscreen display
- Programmable operation with up to 9 programs and 11 customizable steps
- Made in Korea with robust stainless steel components for durability
What’s Included
- Main motor unit
- HMTL HomoMixer tool
- Telescopic stand
- Touchscreen display
- Digital PID controller
- USB port for data backup
- Optional DSTL Disper tool (sold separately)
Technical Specifications
| Specification | Details |
|---|---|
| Speed Range | 500 – 13,000 rpm (no load) |
| Speed Resolution | 50 rpm |
| Maximum Viscosity | 70,000 mPas |
| Maximum Capacity | 3 Liters (at max viscosity) |
| Motor Power | 300 W |
| Direction Control | Forward and Reverse (auto switch) |
| Motor Type | Brushless DC |
| Safety Features | Overload, overcurrent, overheating protection, and error display |
| Material | SUS304 stainless steel (turbine and shaft) |
| Controller | Digital PID with high-performance MCU |
| Timer | 99 minutes, 59 seconds |
| Favorites | Store up to 8 favorite settings |
| Display | 3.5” full-color LCD touchscreen |
| Program Modes | 9 programmable modes, 11 steps |
| Dimensions (Main Unit) | 81 × 263 × 203 mm |
| Weight (Main Unit) | 2.5 kg |
| Packing Dimensions | 750 × 670 × 180 mm |
| Gross Weight | 13.8 kg |
| Power Supply | AC 230V, 50/60 Hz, 350 W |
