Designed to maintain precise temperature and agitation levels, the MaXturdy shaking water bath enables researchers to conduct experiments and studies requiring specific water bath conditions with accuracy. The digital interface allows for easy programming and monitoring, ensuring optimal performance in tasks such as sample incubation, chemical reactions, and other temperature-sensitive procedures.
- With Universal Spring Rack
- Digital Fuzzy Controller Provides Precise Temperature Control
- Digital Feedback Controller Provides Precise Speed Control
- Hi-Performance Shaking engine ensures smooth shaking motion and minimum noise and vibration
- Easy to disassemble Spring Rack for Cleaning
| MaXturdy 18 | MaXturdy 30 | MaXturdy 45 | |
| Capacity | 18L | 30L | 45L |
| Max. Q’ty of Erlenmeyer Flask | 250ml × 6 ea | 250ml × 10 ea | 250ml × 18 ea |
| 500ml × 4 ea | 500ml × 8 ea | 500ml × 15 ea | |
| 1000ml × 1 ea | 1000ml × 3 ea | 1000ml × 8 ea | |
| Temp. Range & Accuracy | Room Temp. +5°C to 100°C , ±0.1°C | ||
| Temp. Resolution | 0.1°C – Display, 0.1°C – Control | ||
| Temp. Uniformity & Probe | ±0.5°C, PT100 | ||
| Heating Power | 1.4kW | 1.8kW | 2.4kW |
| Shaking Speed & Resolution | 20 ~ 250rpm, 1rpm-Display/1rpm-Control | ||
| Shaking Stroke (mm) | 15, 20, 30 Available (20 as factory Default) | ||
| Timer & Alarm | 99hr 59min (Delay & Continuous run), Error status & Timer-end | ||
| Display | Digital LCD with Back-Light Function | ||
| Controller Digital | Fuzzy Controller with Jog-Shuttle Switch (Turn+Push) | ||
| Safety Circuit | Over-Temp./-Current protection, Sensor Error Detection | ||
| Rack | Included Stainless-steel Spring Rack: Universal-type | ||
| Drain Valve | Mounted | ||
| Material | Stainless-steel (#304)-Internal, Powder Coated steel-External | ||
| Internal dimensions (mm) | 300w × 300d × 200h | 500w × 300d × 200h | 600w × 380d × 200h |
| External dimensions (mm) | 563w × 353d × 340h | 763w × 353d × 340h | 863w × 433d × 340h |
| Packing Size (mm) | 620 × 420 × 450h | 820 × 420 × 450h | 920 × 500 × 450h |
| Gross Weight | 24 | 26 | 32 |
| Electric Reqts. | 1 Phase, AC 120V, 60Hz or 230V, 50/60Hz | ||
| Volume | 18Ltr, 30Ltr, 45Ltr |
|---|
