Shaking Incubator for Microplates

Thermo Shaker for Microplates

MB100-2A is designed for shaking 1-2 standard 96 Well Plates in the Thermostating Mode. They are designed using the multi-principal which allows using it as 2 independent devices:

1. Incubator for lasting incubation without shaking of micro-quantities (insect plant cell cultures etc.) in immunoplates
2. Microplate thermo-shaker for immunochemistry and molecular diagnostics where requirements to the result reproducibility and thus to the precise method regulation are particularly high.

A distinctive featuer for the MB100-2A is two-side heating of microtest plates that allows achieving exact correspondence of the set and actual temperature in wells of the microtest plates.

– This device can be used in:

1. Cytochemistry – for situ reactions
2. Immunochemistry – for immunofermentative reactions
3. Biochemistry – for enzyme and protein analysis
4. Molecular Chemistry – for matrix analysis

– Specifications –

Model	MB100-2A
Temp. control range	Ambient+5 °C~70 °C
Timer Range	1 Min ~ 99 h59 min
Temp. control accuracy	±0.5 ℃
Display accuracy	±0.1 ℃
Shaking	100 ~ 1200 rpm
Mixing Orbit	2 mm
Heating time (25°C to 70°C)	≤20 min
Platform Capacity	2 Plates
Dimension (WxDxH) mm	280x270x150 mm
Weight	6.5 kg
